6.3.3 Setpoint Parameters
No. Sign Range Default Description REG
200
Allowed Positive
Deviation
0.1~100.0
%
1.0%
Allowed Positive Deviation
Positive Deviation = Final Feeding Weight –
Target Value.
If ‘Positive Deviation > Target Value × Allowed
Value’, the DO switch ‘
Positive Deviation
Alarm’ will turn on automatically.
40225
201
Allowed
Negative
Deviation
0.1~100.0
%
1.0%
Allowed Negative Deviation
Negative Deviation = Target Value – Final
Feeding Weight.
If ‘Negative Deviation > Target Value ×
Allowed Value’, the DO switch ‘Negative
Deviation Alarm’ will turn on automatically.
40227
202
Non-load Zero
Range
0~60000 20
Non-load Zero Range
Set value = 0: In the auto-dumping process, the
condition ‘Gross Weight ≤ Non-
load Zero
Range’ will be ignored.
Set value > 0: In the auto-dumping process,
‘Gross Weight≤Non-load Zero Range’ will be
used as the judging condition that the materials
in the weighing hopper have been dumped
completely.
40229
203
Target Batch
Count
0~60000 0
Target Batch Count
Set value = 0: No judging ‘
Target Batch
Finished’.
Set value > 0: After Batch Count reached to this
set value, the controller will display prompt
message.
40231
204
#1 Gross Weight
Upper Limit
0~999999 0
#1 Gross Weight Upper Limit
Set value = 0: No judging ‘Gross Weight Upper
Limit’.
Set value > 0: If ‘Gross Weight ≥ Upper
Limit’, the controller will display alarm
message.
40233
205
#2 Gross Weight
Upper Limit
0~999999 0 #2 Gross Weight Upper Limit 40235
206
#3 Gross Weight
Upper Limit
0~999999 0 #3 Gross Weight Upper Limit 40237
207
#4 Gross Weight
Upper Limit
0~999999 0 #4 Gross Weight Upper Limit 40239
