Supmeter BST106-M10 User Manual

47
6.5.2 DI Assignment
No. Sign Range Default Description REG
720
721
722
723
724
725
726
DI1
DI2
DI3
DI4
DI5
DI6
DI7
0~120
0[41]
42
46
0[44]
103
104
0[105]
DI Function Options
0: None
1: #1 E-stop [Emergency Stop]
2: #1 Start
3: #1 Auto-Dumping Permit
4: #1 Manual Dump
5: #1 Clear Alarm
6: #1 Last Batch [Normal Stop]
7: #1 Zero Fine Adjustment
8: #1 Pause
9: #1 Recover Running
10: #1 Manual SP3 Re-feed
11: #1 Manual High-speed Feed
12: #1 Unused
13: #1 Manual Low-speed Feed
14: #1 Manual Feed [High-speed&Low-speed]
15: #1 Start/E-stop [Emergency Stop]
16: #1 Unused
17: #1 Unused
18: #1 Unused
19: #1 Unused
20: #1 Unused
40741
40743
40745
40747
40749
40751
40753
21: #2 E-stop [Emergency Stop]
22: #2 Start
23: #2 Auto-Dumping Permit
24: #2 Manual Dump
25: #2 Clear Alarm
26: #2 Last Batch [Normal Stop]
27: #2 Zero Fine Adjustment
28: #2 Pause
29: #2 Recover Running
30: #2 Manual SP3 Re-feed
31: #2 Manual High-speed Feed
32: #2 Unused
33: #2 Manual Low-speed Feed
34: #2 Manual Feed [High-speed&Low-speed]
35: #2 Start/E-stop [Emergency Stop]
36: #2 Unused
37: #2 Unused
38: #2 Unused
39: #2 Unused
40: #2 Unused
