Supmeter BST106-M10 User Manual

25
4.5.3 DI/DO Connection for APP2 Four-Sacle Mode
DC24V Input - V-
High-speed Feed M1_SP1
Low-speed Feed M1_SP3
High-speed Feed M2_SP1
Low-speed Feed M2_SP3
High-speed Feed M3_SP1
Low-speed Feed M3_SP3
High-speed Feed M4_SP1
Low-speed Feed M4_SP3
Weigher #1 Dump W1_DUMP
Weigher #2 Dump W2_DUMP
Weigher #3 Dump W3_DUMP
Weigher #4 Dump W4_DUMP
DC24V Input + V+
Push Button
Auto/Manual AUTO
START
Last Batch [Normal Stop] LAST
Manual Dumping DUMP_I
Start Mixing Conveyor BELT_START
Stop Mixing Conveyor BELT_STOP
Mixing Conveyor Ready
BELT_RDY
Selector Switch
Push Button
DI
DO [Transistor]
Mixer Control MIXER
Mixing Conveyor Control BELT
Mixing Bin Dumping MIX_DUMP
All Materials Feeding Ended ALL_FED
Alarm/Pause ALARM
－
+
DI1
DI3
DI4
DI5
DI6
DI7
DI2
Push Button
DC24V
Power
V-
DO1
DO2
DO3
DO4
DO5
DO6
DO7
DO8
DO9
DO10
DO11
DO12
V+
Push Button
Push Button
DO13
DO14
DO15
DO16
DO17
DO18
