Supmeter BST106-M10 User Manual

21
4.4 Typical Application: APP1 Single-sacle Mode
4.4.1 System Diagram for APP1 Single-sacle Mode
Parameter [300] ‘Application Mode’= ‘0: APP1 Single-scale Mode’.
No mixer: Parameter [408] ‘Mixing Time Before Mixing Bin Auto-dumping’ =0.
Mixer: Parameter [408] ‘Mixing Time Before Mixing Bin Auto-dumping’ >0.
Weighing Controller
Dumping Gate
Summing Box
Loadcell
SP1 High-speed Feeding Gate / SP3 Low-speed Feeding Gate
M1 M2 M4
Mixing Conveyor
Feeding Hopper M1-M4
。。。
Control Box
Mixing Conveyor Ready
Mixer
Weighing Hopper / Mixing Bin
