20
Note: All of the DI/DO/AO functions can be defined. Refer to ‘6.5 F9 I/O Assignment’.
DO [Transistor, Valid with high-level output voltage 24V]
No. Pin Signal Name Description
1 V- V- DC24V Input -.
2 DO1 M1_SP1 Material M1 High-speed Feed.
3 DO2 M1_SP3 Material M1 Low-speed Feed.
4 DO3 M2_SP1 Material M2 High-speed Feed.
5 DO4 M2_SP3 Material M2 Low-speed Feed.
6 DO5 M3_SP1 Material M3 High-speed Feed.
7 DO6 M3_SP3 Material M3 Low-speed Feed.
8 DO7 M4_SP1 Material M4 High-speed Feed.
9 DO8 M4_SP3 Material M4 Low-speed Feed.
10 DO9 W1_DUMP
Weigher #1 Dump.
ON: Open Dumping Gate. OFF: Close Dumping Gate.
11 DO10 W2_DUMP Weigher #2 Dump.
12 DO11 W3_ DUMP Weigher #3 Dump.
13 DO12 W4_ DUMP Weigher #4 Dump.
14 V+ V+ DC24V Input +.
1 DO13 MIXER Mixer Control.
2 DO14 BELT Mixing Conveyor Control.
3 DO15 MIX_DUMP Mixing Bin Dump [4-Scale]
4 DO16
5 DO17 ALL_FED All Materials Feeding Ended.
6 DO18 ALARM
Alarm/Pause.
ON: Positive/Negative Deviation Alarm.
ON: Gross Weight Upper Limit Alarm.
ON: Feeding/Dumping Overtime Alarm.
Pulse [ON: 1s; OFF: 1s]: Pause State.
