49
No. Sign Range Default Description REG
DI Function Options
81: #4 E-stop [Emergency Stop]
82: #4 Start
83: #4 Auto-Dumping Permit
84: #4 Manual Dump
85: #4 Clear Alarm
86: #4 Last Batch [Normal Stop]
87: #4 Zero Fine Adjustment
88: #4 Pause
89: #4 Recover Running
90: #4 Manual SP3 Re-feed
91: #4 Manual High-speed Feed
92: #4 Unused
93: #4 Manual Low-speed Feed
94: #4 Manual Feed [High-speed&Low-speed]
95: #4 Start/E-stop [Emergency Stop]
96: #4 Unused
97: #4 Unused
98: #4 Unused
99: #4 Unused
100: #4 Unused
101: Start Mixer
102: Stop Mixer
103: Start Mixing Conveyor
104: Stop Mixing Conveyor
105: Mixing Conveyor Ready
106: Mixing Bin Manual Dump [4-Scale Mode]
107: Unused
108: Unused
109: Unused
110: Unused
111: Unused
112: Unused
113: Unused
114: Unused
115: Unused
116: Unused
117: Unused
118: Unused
119: Unused
120: Unused
Refer to ‘4.3 DI/DO Ex-factory Assignment’.
To Next Page
