51
No. Sign Range Default Description REG
733 AO Max. Weight 1~999999 10000
Max. Weight Value for AO1 Output
#1 Weight≥[733.1]: AO1= High Limit Value.
#1 Weight≤0: AO1=Low Limit Value.
40779
Max. Weight Value for AO2 Output
#2 Weight≥[733.2]: AO2= High Limit Value.
#2 Weight≤0: AO2=Low Limit Value.
40781
Max. Weight Value for AO3 Output
#3 Weight≥[733.3]: AO3= High Limit Value.
#3 Weight≤0: AO3=Low Limit Value.
40783
Max. Weight Value for AO4 Output
#4 Weight≥[733.4]: AO4= High Limit Value.
#4 Weight≤0: AO4=Low Limit Value.
40785
734
AO Low/High
Limit
0.00~10.00 0.00 AO Low Limit Value [V] 40787
0.00~10.00 5.00 AO High Limit Value [V] 40789
