Supmeter BST106-M10 User Manual

30
No. Sign Range Default Description REG
108
Stablity Judging
Range
0~99 0
Stablity Judging Range [d: Division]
Weight Variance per [109] ‘
Stablity Judging
Time’ being within [108] ‘
Stablity Judging
Range’ means ‘Weight is stable’.
40125
109
Stablity Judging
Time
0.1~9.9 1.0 Stablity Judging Time [s] 40127
110
SP1
Anti-vibration
Filter1
0~19
3
[13]
SP1 Anti-vibration Filter1
Filter1 is used for setpoint control of SP1
High-speed Feeding.
40129
111
SP3
Anti-vibration
Filter2
0~19 17
SP3 Anti-vibration Filter2
Filter2 is used for setpoint control of SP3
Low-speed Feeding and stable weight display.
40131
Demand:
Filter2’s 10
0
Digit
≥
Filter1’s 10
0
Digit + 2
Filter1&2’s 10
0
Digit Set
Set Value Cutoff Frequency
0 None
1 11.2Hz
2 8.0Hz
3 5.6Hz
4 4.0Hz
5 2.8Hz
6 2.0Hz
7 1.4Hz
8 1.0Hz
9 0.7Hz
Filter1&2’s 10
1
Digit Set
Set Value Anti-Vibration Grade
0 Medium
1 High
112
Weight Display
Smooth Filter3
1~80 20
Weight Display Smooth Filter3
The bigger set value of Filter3 will make the
real-
time weight more stable with slower
response speed.
40133
