Supmeter BST106-M10 User Manual

54
Data Name
Address
Attr.
CMD
[HEX]
Description
#1 #2 #3 #4
Alarm State
41227 41229 41231 41233
R 03
41227.0 1: RAM Fault
41227.1 1: EEPROM Fault
41227.2 1: Parameter Error
Bit3 1: Signal Error
Bit4 1: ADC Fault
Bit5 1: Over ADC Range
Bit6 1: Overload Alarm
Bit7 1: Gross Weight Upper Limit
Bit8 1: Deviation Alarm
Bit9 1: Pause
Bit10 1: Feeding Overtime Alarm
Bit11 1: Dumping Overtime Alarm
Bit12
Bit13
Bit14
41227.15 1: Target Batch Finished
41227.16 1: Last Batch
41227.17 1: ZERO Invalid
Total Totalized Weight 41235 R 03 M1-Mn
Total Batch Count 41237 R 03
Auto/ Manual switch 41401 W 10
0xFF: Auto/Manual switch.
0xA5/A6/A7/A8:
#1/#2/#3/#4 Stop
Start/Stop Control 41403 W 10
0x55/56/58/59:
#1/#2/#3/#4 Start
0x57: All Start
0x5C: Last Batch [Normal Stop]
0x5D/5E/5F/60:
#1/#2/#3/#4 Last Batch
41405 W 10 0x55: Unused
