IntelliShot & FlexoShot: Operations Manual Page 1
INTRODUCTION
MAIN COMPONENTS OF INTELLISHOT (PORTION-CONTROL)
Figure 1: Main exterior components of the AC110-PC
Actual dairy dispenser may not be exactly as shown.
Figure 2: Main interior components of the AC320-FP
Actual dairy dispenser may not be exactly as shown.
2. Side console (temp
display/adjustment)
3. Power switch
4. Circuit breaker
5. Dispenser door
6. Button panel
7. Thumbscrew on valve door
8. Dispense point
9. Front panel
10.
Catch tray
2. Job aid
3. Dispenser flip lid
4. Tank flip lid
5. Product tank
