IntelliShot & FlexoShot: Operations Manual Page 3
SPECIFICATIONS
Model: AC10 AC20 AC30
Weight (empty): 60 lbs / 27 kg 75 lbs / 34 kg 80 lbs / 36 kg
Dimensions*
(LxWxH):
18" x 9.5" x 24"
46 x 24 x 61 cm
22" x 12" x 24"
56 x 31 x 61 cm
23.75" x 15.5" x 24"
61 x 40 x 61 cm
*Height is based on dispensers with 1-inch (2.5 cm) legs. Dispensers with 4-inch (10.1 cm) legs should
add 3-inch (7.6 cm) to the height.
Table 1: Specifications
POWER REQUIREMENTS
To identify the dispenser’s power requirements, refer to the product identification label located on the
lower left side of the dispenser.
Table 2: Power requirements
SOUND LEVEL (DBA)
The A-weighted sound pressure level is below 70 dB.
REFRIGERANT
The dispenser contains fluorinated gas (R134a) with global warming potential (GWP) equivalent in
metric tons of CO2.
Model R134a (g) GWP (t)
AC10 110 0.157
AC20 120 0.172
AC30 140 0.200
Table 3: Refrigerant
120 V AC, 1 amp, 1 ph, 60 Hz
220-240 V AC, 1 amp, 1 ph, 50/60 Hz
