Table 2-1. Configuration switch settings for different angles of steepness.
Angle
DIP switch number
1
2
3
4
7
1
1
1
1
11
0
1
1
1
14
1
0
1
1
21
0
0
1
1
27
1
1
0
1
29 *
0
1
0
1
35
1
0
0
1
39
0
0
0
1
45
1
1
1
0
Angle
DIP switch number
1
2
3
4
39
0
1
1
0
35
1
0
1
0
29
0
0
1
0
27
1
1
0
0
21
0
1
0
0
14
1
0
0
0
11
0
0
0
0
*Factory default near 30
degrees
Switches 5, 6 and 7 set the direction of the movement produced by a clockwise turn
(advancing right hand screw) of the ROE knob for each axis.
With the switch set to 0, a clockwise turn of the knob produces a decrement in the display;
when the switch is set to 1, a clockwise turn of the knob produces an increment in the
display. An increment in the display coincides with movement downward in the Z axis,
