MPC-385 SERIES OPERATION MANUAL – REV. 3.21K (20201120)
57
APPENDIX D. TECHNICAL SPECIFICATIONS
D.1. MP-285/M
Resolution Minimal microstep size is 62.5 nanometers per
microstep. Display has single micron resolution.
Speed 5 mm/sec. maximum
Drift < 1 micron/hr drive mechanism
D.2. MPC-200 Controller
Dimensions (H x W x D): 4 x 15.94 x 11 in (10.16 x 40.49 x 27.94 cm)
Weight: 6.65 lb. (6 lb., 10.4 oz.; 3.02 kg)
Electrical:
Input voltage (Mains) 100 - 240 V, 50/60 Hz
Power consumption 170 Watts maximum per MPC-200 controller
(340W max. for an MPC-385-3 or MPC-385-4
system)
Mains fuses (rear of cabinet) refer to the FUSE REPLACEMENT appendix for
details
Cables (Refer to the following tables for a description of
all possible cables.)
Table 6-1. MPC-385 Controller cables and receptacles/connectors.
Controller Rear Panel
Port
Connector/Receptacle
Cable Connector
Types
Connects to ...
Cable Type
Cable
Max.
Length
MPC-200: (Power entry)
3-pin male connector
 3-pin power
standard (female)
|
3-pin male

(
Geographical region
dependent)
Mains power source.
10A, 250V, with
safety ground
plug
3 meters
(approx.
10 feet)
