Sutter Instrument MPC-200 - External Control Summary

58
MPC-385 SERIES OPERATION MANUAL – REV. 3.21K (20201120)
Controller Rear Panel
Port
Connector/Receptacle
Cable Connector
Types
Connects to ...
Cable Type
Cable
Max.
Length
MPC-200 Controller
Cabinet:
MANIPULATOR A
or
MANIPULATOR B
(each a 25-Pin DSUB
female receptacle

DB-25 male
|
DB-25 female

(Straight-through)
MP-285M
Minimum of 26
awg stranded
wire with 500
Volt.
3 meters
(approx.
10 feet)
MPC-200: COMMAND
INPUT and
ROE-200 CONTROLLER

RJ45 male
|
RJ45 male

ROE-200 User Input
Device receptacle
named
“CONTROLLER”
MPC-200: EXPANSION

RJ11 male
|
RJ11 male

a second MPC-200
controller (and its
EXPANSION
receptacle)
ROE-200: USB
USB ”A” (Device) female
receptacle (full-sized)

A connector
|
B connector

Host computer’s USB
“B” receptacle (full-
sized)
Dielectric
separation of
circuits. Foil
shielding.
3 meters
(approx.
10 feet)
D.3. ROE-200
Dimensions: 10 x 6 x 4 in (25.4 x 15.24 x 10.16 cm)
Weight: 3.5 lbs. (1.6 kg)
