MPC-385 SERIES OPERATION MANUAL – REV. 3.21K (20201120)
Table 5-10. Move to controller-defined HOME position (‘H’) command.
Move to
Home
Position
1
(‘H’)
5.8.7 Move to Controller-Defined WORK Position (‘Y’) Command
This command moves to the position defined last defined for the WORK key. Movement is
equivalent to pressing the WORK key.
Table 5-11. Move to controller -defined WORK position (‘Y’) command.
Move to
Work
Position
2
(‘Y’)
5.8.8 Move to Center Position (‘N’) Command (FW =< 1.03)
This command moves to the center position (midpoint between beginning of travel and end of
travel positions). Movement is equivalent to pressing the CENTER key.
NOTE: This command (‘N’) along with the momentary “CENTER” switch on the back of the
ROE-200 have the “Move to Center Position” functionality only in a system programmed
with Firmware version 1.03 or lower.
Table 5-12. Move to Center Position (‘N’) command (FW <= 1.03).
Move to
Center
Position (‘N’)
5.8.9 Calibrate (‘N’) Command (FW > 1.03)
This command moves to the Beginning Of Travel (BOT) position. It has the same
functionality as pressing the momentary “CALIBRATE” switch on back of the ROE-200.
1
The “Home Position” is defined manually on the ROE-200.
2
The “Work Position” is defined manually on the ROE-200.
