SV 104A USER'S MANUAL_______________________________________________________
53
6.4 Instrument options unlock
Certain features of SV 104A such as 1/1 octave or 1/3 octave measurement or time domain signal
recorder are not available before activation. Activation of these options is fairly easy and can be done in a few
steps:
1. Connect the dosimeter to a computer
2. Launch Supervisor software
3. In the instruments inventory panel (Chapter 6.3) locate the instrument that you wish to unlock,
and right click onto it to open context menu.
4. Select Manage options/functions command
Figure 6-4 Unlocking the firmware options
5. In the Manage options / functions window click the Unlock button next to the feature you wish
to unlock
6. Enter the code and confirm with OK button
