3.2 Input output interfaces description
SV 104IS instrument is equipped with a set of useful interfaces:
 microphone connector (essential for measuring)
 charging connector (for use with docking station.)
 infrared port (for use with docking station)
Figure 3-2 SV 104IS side view – microphone connector
Figure 3-3 SV 104IS back view - charging and infrared port
microphone
mounting head
infrared
port
charging
connector
RX
TX
