SV 104IS USER’S MANUAL______________________________________________________
35
Figure 4-12 Calibration - microphone not in tolerance screen
9. Post calibration. If enabled, the post processing is performed automatically under acceptance
of calibration measurement.
Notice: If it is required to perform so called post-calibration of the instrument. In case
the Post Calibration is pre-programmed within configuration setup the SV 104IS automatically adds
the results to the previously saved files.
Notice: Calibration with use of SV 34 is allowed only in safe area.
