SV 104IS USER’S MANUAL ______________________________________________________
32
4.6 Measurement setups - basic configuration
Press two keys <SCROLL> and <ENTER> at the same time. The “Load Setup” menu
will appear with the list of loaded configuration setups to choose.
Figure 4-5 Load setup menu
To abandon setup selection, press again the <SCROLL> and <ENTER> at the same time.
Otherwise select the required configuration setup with <ENTER> key navigating thru the list with
<SCROLL> or <PROFILE> key.
The following screen will appear, that will allow you to confirm you really want to load the selected
setup or cancel the selection and return to configuration setup list:
Figure 4-6 Load setup confirmation
Press <SCROLL> key to cancel the setup loading, or <PROFILE> key to confirm loading
selected setup configuration.
Confirming the loading of configuration setup leads to the screen with status of the loading procedure:
Figure 4-7 Status of setup loading
After successfully setup loading it is possible to return back to list of predefined setups by pressing
the <SCROLL> key, or go further to measurement screen by pressing the <PROFILE> key.
Notice: Detailed description of uploading setup files onto the SV 104IS can be found in
chapter 5.5.1 of this manual .
