SV 104IS USER’S MANUAL ______________________________________________________
46
For example: To download current settings file from the SV 104IS, modify it, save with custom name,
send it back to the device, export the setup to USB flash memory, and make sure the uploaded settings
are applied in the dosimeter follow the presented procedure described below:
Once connected and selected in the inventory panel (Figure 5-3) SV 104IS dosimeter is ready for
the operation:
1. Select the “Settings” row position in left side panel named “Instrument files” (Figure 5-5)
2. Click the right arrow pictogram to download instrument “Settings” configuration setup to “Local
files” right side panel (Figure 5-5)
3. Select the just copied “Settings” with a click: this will display quite a few configuration tabs
on the right side so called Instrument configuration panel of the main Supervisor window (Figure
5-2)
4. Go through all the tabs to verify, or change required parameters of the measurement runs.
Follow the chapters from 5.5.2 to 5.5.9 to understand and configure the instrument
5. Once configured, come back to setups file manager (Figure 5-5) and click the just edited “Settings”
in “Local files” panel
6. Next click the “Save” button in bottom area of the panel (Figure 5-5)
7. To change the name right click on the selected row, and choose “Rename” command, which
enables you to input a custom name for the setup that has just been edited (see the figure below)
8. To export the setup file right click again on the selected row to open context menu and select
the “Export” command (see the figure below). This will open standard save file window, where you
can choose the USB flash memory disk, and save the configuration file to use on a different PC.
Note, it is also possible to import the previously saved settings file to re-use a created setup
configuration.
9. To import the setup file right click on the ”Local files” panel, and choose “Import” command (see
the figure below). This will open standard open file window, where you can choose previously
created setup and load it into the “Local files” panel.
Figure 5-6 Exporting the configuration setup file
upload
selected
setup file
To Next Page
