1. GENERAL INFORMATION
1-9
Standard Torque Values for Reference
Type Torque value kgf-m
5 mm Bolt, Nut 0.45 - 0.6
6 mm Bolt, Nut 0.8 - 1.2
8 mm Bolt, Nut 1.8 - 2.5
10 mm Bolt, Nut 3.0 - 4.0
12 mm Bolt, Nut 5.0 - 6.0
5 mm Screw 0.35 - 0.5
6 mm Screw & 6mm bolt with 8mm head 0.7 - 1.1
6 mm Flange bolt, nut 1.0 - 1.4
8 mm Flange bolt, nut 2.4 - 3.0
10 mm Flange bolt, nut 3.5 - 4.5
