Sym Joyride125 - V-Belt Driving System and Kick Starter

8. V-BELT DRIVING SYSTEM/KICK STARTER
8-1
Mechanism Diagram ..................... 8-1 Kick starter .....................................8-3
Maintenance Description.............. 8-2 Driving belt .....................................8-5
Trouble Diagnosis......................... 8-2 Drive face........................................8-6
Left crankcase cover..................... 8-3 Clutch outer/Driven pulley.............8-10
8
5.0~6.0 kgf-m
5.0~6.0 kgf-m
3.5~4.5 kgf-m
