14. BRAKE
14-1
Illustration - Front Disc Brake
System ....................................................14-1
Illustration - Rear Disc Brake
System ....................................................14-2
Maintenance Description.......................14-3
Trouble Diagnosis..................................14-4
Hydraulic Disc brake.................................14-5
Air Bleed ....................................................14-6
Brake Calliper ..........................................14-6
Brake Disc ................................................14-7
Brake Master Cylinder...............................14-7
Front Disc Brake System
4.5 kgf-m
1.8 kgf-m
0.55 kgf-m
3.5 kgf-m
