2. MAINTENANCE INFORMATION
2-4
AIR CLEANER
Remove trunk.
Remove side cover.
Remove 8 screws from the air cleaner cover and
then remove the cover.
Caution
Air cleaner element contains a paper made
filter so do not try to clean it.
CRANKCASE VENTILATION
Pull out the plug from draining hose to clean
deposit.
Caution
When always riding in rainy area or full
throttle position, maintenance travel must be
shorted. The deposits can be seen in the
transparent section of draining hose.
SPARK PLUG
Recommended spark plug: CR8E
Remove trunk.
Remove central cover.
Remove spark plug cap.
Clean dirt around the spark plug hole.
Remove spark plug.
Measure spark plug gap.
Spark plug gap
：
0.8~0.9 mm
Carefully bend ground electrode of the plug to
adjust the gap if necessary.
Hold spark plug washer and install the spark
plug by screwing it.
Tighten the plug by turning 1/2 turn more with
plug socket after installed.
Connect spark plug cap.
To Next Page
