1. GENERAL INFORMATION
1-8
Torque values
Item Q’ty
Thread Dia.
(mm)
Torque Value
(Kgf-m)
Remarks
Cylinder head bolt
4 8 2.0-2.4
Valve clearance adjust nut
4 5 0.7-1.1
Apply oil to thread
Spark plug
1 10 1.0-1.4
L. Crankcase cover bolts
7 6 1.1-1.5
Crankcase bolts
7 6 0.8-1.2
Oil drain bolt
1 8 1.1-1.5
Oil strainer cap
1 30 1.3-1.7
Gear oil drain bolt
1 6 1.0-1.4
Gear oil inspection bolt
1 6 1.0-1.4
Transmission cover bolt
7 6 1.0-1.4
Flywheel bolt
1 14 5.0-6.0
Clutch driving plate bolt
1 28 5.0-6.0
Driving disc nut
1 12 5.0-6.0
Clutch outer cover nut
1 10 3.5-4.5
Transmission cover bolts
7 6 1.0-1.4
Stopper nut for engine hanger
bracket
1
8
1.8-2.2
Nut for engine hanger bracket
1 10 4.0-5.0
Bolt for engine hanger bracket
1 10 4.0-5.0
Engine mounting bolt
1 10 3.5-4.5
Front wheel shaft nut
1 12 5.0-7.0
Rear wheel shaft nut
1 14 11.0-13.0
Bolt for rear shock absorber (upper)
2 10 3.5-4.5
Bolt for rear shock absorber (under)
2 8 2.4-3.0
Bolt for steering rod
1 10 4.0-5.0
Front shock absorber
4 8 2.4-3.0
Brake arm bolts
2 6 0.8-1.2
Brake hose bolts
4 10 3.3-3.7
Bolt for brake caliper
4 10 3.0-3.5
Bolts for the lining guide pin
4 6 1.6-2.0
Brake disk bolts
7 10 4.0-4.5
Mounting screw for speedometer
cable
1
5
0.15-0.3
Muffler bolts
4 8 3.2-3.8
Mounting bolts for exhaust pipe
connection
2
7
1.0-1.2
The torque values listed in above table are for more important tighten torque values. Please see
standard values for not listed in the table.
