To this chapter contents
12. Rear Wheel / Rear Cushion
Drive Chain / Sprocket / Flange
Drive chain / sprocket removal
Remove the left crankcase rear cover (bolt×2).
12-8
Bolt×2
Remove the drive sprocket fixing plate.
Bolt×2
Remove the drive chain cover.
Remove the drive chain fixing clip.
Remove the drive chain.
Fixin
g
cli
p
