To this chapter contents
12. Rear Wheel / Rear Cushion / Swingarm
12-7
Tighten the drive chain adjusting nut slightly to
prevent it from loosening.
Install the rear brake torque link.
Torque value：1.8~2.5kgf-m
Install the rear brake rod and adjusting nut.
Adjust the rear brake pedal free play.
Rear brake pedal free play：20~30mm
Adjusting nut×2
Adjusting nut
Nut×1
20~30mm
