4
、
Lubrication / Clutch / Transmission
Install the alignment pin and a new right
crankcase gasket.
4-11
Install the right crankcase cover. ( Bolt X 11 )
Torque Value：0.8~1.2kgf-m
Assemble the clutch cable.
Assemble the kick-starter, lever, and the
exhaust pipe.
Fill in the specified engine oil.
Adjust the clutch lever free play.
Free play：10~20mm
Alignment pin
Bolts×11
Clutch cable
Bolt×1
10~20mm
