6. Engine Removal
Engine Removal
6-2
Drain all the engine oil out.
Remove the left body cover.
Remove the battery cable, first negative then
positive pole.
Remove the battery
Caution
z To prevent short circuit, always connect
the positive pole before the negative one.
Remove the seat cushion, separate the wire
band, and remove the AC.G coupler.
Remove the starting motor power cable.
ACG coupler
Engine oil drain bolt
Negative pole
Positive pole
Starting motor power cable
To Next Page
