6. Engine Removal
Remove the PCV tube.
6-3
Remove the
AICV tube.
Loosen the choke cable holder screw
(screwX1), and remove the choke cable.
Disassemble the carburetor top cover by
turning
counterclockwise. Then
remove
the
top
cover,
throttle
cable,
and
the
throttle
body.
PCV tube
AICV tube
Choke cable
hl
d
Top cover
Throttle body
