Symmetricom TimeProvider 500 series User Manual

Issue 3: Mar 96 TMSL 097-45018-02
Page 25
INITIALIZE REGISTER T1 (Contd)
tmper: For PSM only:
15-MIN = time period of the register to be initialized (always 15-MIN)
<null> = current time period
mondat: For PSM only:
mm-dd = date of the first initialization register
<null> = current date
montm: For PSM only:
hh-mm = start of the first register to be initialized (e.g., 14-00, 14-15, 14-30,
14-45) (registers are initialized from this point to the current reg-
ister)
<null> = current time
Examples:
INIT-REG-T1::MRC-1-4:143::BPV,5;
The above example, if E1 is the input, tagged as command 143, sets the current BPV performance-
monitoring register to 5 at MRC A, span 4.
The above example, if analog is the input, will be denied, and an IDNV error code produced.
INIT-REG-T1::PSM-1-ALL:144::,,,,,15-MIN,06-22,14-30;
The current date and time in this example are June 23 (06-23) and 2:17 pm (14-17). The example
above, tagged as command 144, sets all 24 hours of PSM performance-monitoring registers to zero,
losing all stored maintenance data.
COMPLETED RESPONSE
<sid> <date> <time>
M <ctag> COMPLD
;
Example:
TELECOMSOLUTIONS 96-02-08 15:04:14
M 143 COMPLD
;
ERROR RESPONSE
<sid> <date> <time>
M <ctag> DENY
<errcde>
;
