RETRIEVE ALARMS (MANUAL AND AUTOMATIC)
Displays alarms for all or specific equipment RTRV-ALM- {ALL|EQPT|T1} 46 No
Displays the occurrence of alarmed events REPT-ALM- {EQPT|T1} 54 No
Displays the occurrence of nonalarmed events REPT-EVT 58 No
Displays alarms and events in 64-event system log RTRV-LOG 61 No
CARD INFORMATION AND DATE
Displays notification code and condition type associ-
ated with a specific event
RTRV-ATTR-T1 63 No
Displays condition of all or specific equipment that is
not in alarm
RTRV-COND- {EQPT|T1} 66 No
Displays sid, date, and time (to verify equip. data path) RTRV-HDR 72 No
Displays communications port configuration informa-
tion for a specific port
RTRV-EQPT 74 No
Displays performance-parameter data RTRV-PRMTR-T1 77 No
Displays performance-monitoring data RTRV-PM-T1 79 Yes
Displays threshold for equipment parameter RTRV-TH-T1 83 Yes
Table B. Task/Command Cross-reference (Contd)
TASK COMMAND / MESSAGE PAGE
CAN BE
PROTECTED
G. Alarm Message Format
3.13
In the event an alarm is detected, a message is
displayed on the terminal. The alarm message format
displayed is as follows:
"<aid>:<ntfcncde>,<condtype>,<srveff>: \"[<cond-
descr>]\"
3.14
The
<aid>
is the equipment that the command
affects.
3.15
The
<ntfcncde>
is the notiÞcation code, indi-
cating the severity of the alarm or event.
3.16
The
<condtype>
is the condition type which in-
dicates the type of alarm condition reported as either
raised or cleared, which is also further explained in
the conddescr parameter.
3.17
The
<srveff>
is the service effectivity which
identiÞes how the alarm condition affects service.
3.18
The
<condescr>
is a text description of the
alarm or condition reported by the system, enclosed
within escaped quotes(\'').
3.19
Refer to Table C for a list of alarm messages;
the table is divided into two sections, one for alarm
messages received from the GTI and the other section
lists system alarm messages. The section for the GTI
messages lists the entire terminal display; the sec-
tion for the system messages lists only the condition
description. Refer to Table A for additional informa-
tion regarding the parameters for the alarm message
format.
