Symmetricom TimeProvider 500 series User Manual

TMSL 097-45018-02 Issue 3: Mar 96
Page 86
RETRIEVE THRESHOLD T1
(RTRV-TH-T1)
MESSAGE CATEGORY: SURVEILLANCE
TYPE: INPUT/RESPONSE
This command retrieves and displays the threshold level for a monitored parameter. When the parame-
ter exceeds the threshold value, an automatic message is sent. The threshold may apply to one or more
units.
COMMAND
RTRV-TH-T1:[<tid>]:<aid>:<ctag>[::<montype>];
aid: MRC-1-x = Multi-Reference Controller A (x = span 1 to 4 or ALL)
MRC-2-x = Multi-Reference Controller B (x = span 1 to 4 or ALL)
PSM-x-y = Precision Sync Monitor card (x = 1 to 9, y = span 1 to 4 or ALL)
montype: AIS = alarm indication signal
BPV = bipolar violations
CRC = cyclic redundancy check errors
OOF = out of frame errors
LOS = loss of signal
<null> = all the above montypes
Note: If the aid is MRC-1-x or MRC-2-x, and analog is the input, the montypes AIS,
BPV, CRC, OOF, and LOS have -1 as a threshold.
montype: For PSM only:
MTIE1 = maximum time interval error at 1 second
MTIE4 = maximum time interval error at 4 seconds
MTIE16 = maximum time interval error at 16 seconds
MTIE64 = maximum time interval error at 64 seconds
MTIE128 = maximum time interval error at 128 seconds
MTIE512 = maximum time interval error at 512 seconds
MTIE900 = maximum time interval error at 900 seconds
TVAR1 = time variance error at 1 second
TVAR4 = time variance error at 4 seconds
TVAR16 = time variance error at 16 seconds
TVAR64 = time variance error at 64 seconds
TVAR128 = time variance error at 128 seconds
<null> = all the above montypes
Example:
RTRV-TH-T1::MRC-1-1:136::BPV;
This example, for either E1 or analog input, tagged as command 136, retrieves and displays the
BPV errors for span 1 on MRC-1.
