TMSL 097-45018-02 Issue 3: Mar 96
Page 64
RETRIEVE ATTRIBUTE T1
(RTRV-ATTR-T1)
MESSAGE CATEGORY: SURVEILLANCE
TYPE: INPUT/RESPONSE
This command retrieves and displays the notification code associated with the specified event. Alarmed
events are reported automatically by the REPORT ALARM message. Use the <aid>, <ntfcncde>, and
<condtype> parameters together or separately to display the notification code, or the type of events.
COMMAND
RTRV-ATTR-T1:[<tid>]:<aid>:<ctag>::[<ntfcncde>],[<condtype>];
aid MRC-1-x = Multi-Reference Controller A (x = span 1 to 4 or ALL)
MRC-2-x = Multi-Reference Controller B (x = span 1 to 4 or ALL)
PSM-x-y = Precision Sync Monitor card (x = 1 to 9, y = span 1 to 4 or ALL)
ntfcncde: CR = critical alarm
MJ = major alarm
MN = minor alarm
NA = not alarmed
NR = not reported (see Note below)
<null> = not alarmed
condtype: AIS = alarm indication signal
BPV = bipolar violations
CRC = cyclic redundancy check errors
LOS = loss of signal
OOF = out of frame errors
<null> = all the above condtypes
condtype: For MRC-E and MRC-EA only:
FFREQ = fractional frequency exceeded
<null> = all condtypes, including those listed previously
Note: If the aid is MRC-1 or MRC-2, and analog is the input, the AIS, BPV, CRC, and
OOF condtypes have NR (not reported) notification codes (ntfcncde); LOS and FFREQ
are not affected.
condtype: For PSM only:
MTIE1 = maximum time interval error at 1 second
MTIE4 = maximum time interval error at 4 seconds
MTIE16 = maximum time interval error at 16 seconds
MTIE64 = maximum time interval error at 64 seconds
MTIE128 = maximum time interval error at 128 seconds
MTIE512 = maximum time interval error at 512 seconds
MTIE900 = maximum time interval error at 900 seconds
TVAR1 = time variance error at 1 second
TVAR4 = time variance error at 4 seconds
TVAR16 = time variance error at 16 seconds
TVAR64 = time variance error at 64 seconds
TVAR128 = time variance error at 128 seconds
<null> = all condtypes
