Issue 3: Mar 96 TMSL 097-45018-02
Page 9
Table C. Terminal Alarm Displays
DISPLAY MEANING
GTI MESSAGES
''GTI-x:GPS-FREQTOL,SC:\''GPS FREQ TOL\'' The GTI has determined that, compared to oscil-
lators A and B, the GPS timing solution from the
GTR is out of tolerance (factory set) (x = 1 or 2).
''GTI-x:MN,OSCA-LOS,SA:\''OSC LOSS OF SIGNAL\'' The GTI detects no signal energy on OSC A
input (x = 1 or 2).
''GTI-x:MN,OSCB-LOS,SB:\''OSC LOSS OF SIGNAL\'' The GTI detects no signal energy on OSC B
input (x = 1 or 2).
''GTI-x:MJ,GPS-LOS,SA:\''GPS LOSS OF SIGNAL\'' The GTI detects no signal energy on the GTR
fiber link. This condition has exceeded the
period of time set via DIP switch and has esca-
lated into a major alarm (x = 1 or 2).
''GTI-x:MN,GPS-INVLD,NSA:\''GPS INVALID The timing information from the GTR has been
determined to be invalid for timing at this time
(x = 1 or 2).
''GTI-x:MN,GTI-OUTFLT,SA:\''GTI OUT FAULT\'' The primary rate output of the GTI has been
faulted by a short, improper termination, or
equipment failure (x = 1 or 2).
''GTI-x:MN,GTR-PWR,SA:\''GTR POWER FAULT\'' The GTR power supply has been faulted by a
short, an open, or equipment failure (x = 1 or 2).
''GTI-x:MN,FB,SA:\''FUSE OR POWER FAIL\'' A fuse of the DCD-LPR shelf has blown, or an
office battery has failed (x = 1 or 2).
''GTI-x:MN,GTI-FAILxx,SA:\''GTI FAIL\'' The GTI has experienced a failure. Where x = 1
or 2, and xx = 1 through 3. The xx numbers are
diagnostic codes for field service/engineering
use only.
''GTI-x:MN,GTR-FAILxx,SA:\''GTR FAIL\'' The GTR has experienced a failure. Where x =
1 or 2, and xx = 1 through 5. The xx numbers
are diagnostic codes for field service/engineer-
ing use only.
