Issue 3: Mar 96 TMSL 097-45018-02
Page 81
RETRIEVE PERFORMANCE MONITORING T1
(RTRV-PM-T1)
MESSAGE CATEGORY: SURVEILLANCE
TYPE: INPUT/RESPONSE
This command retrieves and displays the current set of PM data for one or more equipment units or fa-
cilities. The PM data may be used to load or verify a database, to examine events that are not reported
by automatic messages, or to evaluate the system after maintenance operations. Parameters are provid-
ed to display past PM data if the MIS card is configured to store such data. PM data is retrieved from the
specified time period to the current time period.
COMMAND
RTRV-PM-T1:[<tid>]:<aid>:<ctag>::[<montype>],,,,[tmper],
[mondat],[montm];
aid: MRC-1-x = Multi-Reference Controller A (x = span 1 to 4 or ALL)
MRC-2-x = Multi-Reference Controller B (x = span 1 to 4 or ALL)
PSM-x-y = Precision Sync Monitor card (x = 1 to 9, y = span 1 to 4)
montype: For PSM only:
BPV = bipolar violations
CRC = cyclic redundancy check errors
OOF = out of frame errors
LOS = loss of signal
AIS = alarm indication signal
MTIE = maximum time interval error has occurred
MTIE1 = maximum time interval error at 1 second
MTIE4 = maximum time interval error at 4 seconds
MTIE16 = maximum time interval error at 16 seconds
MTIE64 = maximum time interval error at 64 seconds
MTIE128 = maximum time interval error at 128 seconds
MTIE512 = maximum time interval error at 512 seconds
MTIE900 = maximum time interval error at 900 seconds
TVAR1 = time variance error at 1 second
TVAR4 = time variance error at 4 seconds
TVAR16 = time variance error at 16 seconds
TVAR64 = time variance error at 64 seconds
TVAR128 = time variance error at 128 seconds
PHASE = 1 minute average raw phase value as computed by the
PSM-E
SLIPS = number of slips in a given time period
TOTALSLIP = number of slips in a specified 24-hour time period
<null> = not allowed
