TMSL 097-45018-02 Issue 3: Mar 96
Page 24
INITIALIZE REGISTER T1
(INIT-REG-T1)
MESSAGE CATEGORY: SURVEILLANCE
TYPE: INPUT/RESPONSE
This command initializes the specified performance-monitoring storage registers on the specified equip-
ment, and sets the register to the specified value. These registers contain PM information accumulated
in previous intervals. The SET-ATTR-LOG command clears the 64-event system log. The INIT-SYS com-
mand performs a Òcold restartÓ, clearing all system registers.
Note:
This command may be issued only once every 60 seconds.
COMMAND
INIT-REG-T1:[<tid>]:<aid>:<ctag>::[<montype>],[<monval>]
[,,,[<tmper>],[<mondat>][,<montm>]];
aid: MRC-1-x = Multi-Reference Controller A (x = span 1 to 4 or ALL)
MRC-2-x = Multi-Reference Controller B (x = span 1 to 4 or ALL)
PSM-x-y = Precision Sync Monitor card (x = 1 to 9, y = span 1 to 4
or ALL)
montype: AIS = alarm indication signal
BPV = bipolar violations
CRC = cyclic redundancy check errors
OOF = out of frame errors
LOS = loss of signal
<null> = all montypes
Note:
If the aid is MRC-1-x or MRC-2-x, the montypes AIS, BPV, CRC, OOF, and LOS
are to be used only if E1 is selected as the input; if analog is the input, and AIS, BPV,
CRC, OOF, or LOS are the montypes, the command will be denied.
montype: For PSM only:
MTIE1 = maximum time interval error at 1 second
MTIE4 = maximum time interval error at 4 seconds
MTIE16 = maximum time interval error at 16 seconds
MTIE64 = maximum time interval error at 64 seconds
MTIE128 = maximum time interval error at 128 seconds
MTIE512 = maximum time interval error at 512 seconds
MTIE900 = maximum time interval error at 900 seconds
TVAR1 = time variance error at 1 second
TVAR4 = time variance error at 4 seconds
TVAR16 = time variance error at 16 seconds
TVAR64 = time variance error at 64 seconds
TVAR128 = time variance error at 128 seconds
<null> = all of the above montypes
monval: x = value in the performance-monitoring register
<null> = zero
