Issue 3: Mar 96 TMSL 097-45018-02
Page 69
RETRIEVE CONDITIONS (Contd)
aid: For RTRV-COND-ALL and RTRV-COND-EQPT:
CLK-1 = Stratum clock unit A
CLK-2 = Stratum clock unit B
FUSE-1 = fuse A
FUSE-2 = fuse B
MIS = Maintenance Interface, System
MRC-1 = Multi-Reference Controller A
MRC-2 = Multi-Reference Controller B
MRC-ALL = all Multi-Reference Controllers
PSM-x = Precision Sync Monitor card (x = 1 to 9 or ALL)
aid: For RTRV-COND-T1:
MRC-1-x = Multi-Reference Controller A (x = span 1 to 4
or ALL)
MRC-2-x = Multi-Reference Controller B (x = span 1 to 4
or ALL)
PSM-x-y = Precision Sync Monitor card (x = 1 to 9,
y = span 1 to 4 or ALL)
aidtype: T1 = RTRV-COND-T1 command was sent
ntfcncde: For condtype:
CR =critical alarm
MJ = major alarm
MN = minor alarm
NA = not alarmed
NR = not reported
For state:
<null> = ntfcncde has no meaning
condtype: AIS = alarm indication signal
FA = fuse alarm
FRNGSYNC = clock in the freerunning mode
FSTSYNC = clock in the fast-converge mode
HLDOVRSYNC = clock in the holdover mode
INT = card failed
LOS = loss of signal
NORMAL = input reference or clock is active
SFI = loss of stratum input to MRC
SLTMSIG = input references unlocked
SYNC = input reference failed
SYNCCLK = output port failed
SYNCPRI = loss of all primary timing references
SYNCSEC = loss of all secondary timing references
TBPV = threshold for BPVs has been exceeded
TCRC = threshold for CRCs has been exceeded
TFFREQ = threshold for fractional frequency has been ex-
ceeded
