Summary of Symphony LED Operation
AUI LED Operation
AUI has four LEDs labeled - WEB, ARMED, READY and MESSAGE. WEB and
MESSAGE LEDs are yellow. ARMED LED is red and READY LED is green. Each
LED's on and off state has different meanings during different operations.
Following states use LEDs to represent different sub-states.
•
Normal (Idle) State
•
Software Download State
•
Software Download State - Failure Modes
Each LED can have four different states - ON, OFF, FAST BLINK and SLOW
BLINK. All LEDs do not use all of the above states. Details are provided below.
LEDs During Normal (Idle) State
LED DESCRIPTION
WEB ON – Connected to internet
OFF – not connected
FAST BLINK - either sending or receiving data
SLOW BLINK – connecting to server (BB) or dialing to RAS server (DU)
ARMED ON – Security system is armed
OFF – Security system is not armed
READY ON – Security system is disarmed and ready to arm
OFF – Security system is disarmed but not ready. Faults/troubles present
MESSAGE If Message Center is connected to system
OFF - No new messages or memos
FAST BLINK - At least one new memo or message
If Message Center is not connected then it is unused.
LEDs During Software Downloading
LED DESCRIPTION
WEB ON – obtained IP address (via either DHCP client or static IP assignment) (BB)
or established link to RAS server (DU)
OFF – not connected
SLOW BLINK – connecting to server (BB) or dialing (DU)
ARMED ON – connected to server
OFF –
FAST BLINK – could not connect to server (no route or authentication failure)
SLOW BLINK – connecting to server
READY ON – successfully downloaded configuration data
FAST BLINK – could not download configuration data or if with ARMED FAST
BLINK then it connected to server but failed authentication
OFF –
