              22/220 Series Controller Application Manual
Controller Parameter Setting–22
No. Name Value Description
201~2
03
Encoder type Depends 0：Incremental, 3：Absolute
221~2
23
Axis type 0 X/Y/Z are all linear
321~3
23
Axis name 100
200
300
X/Y/Z
901~9
03
Zero speed check window Depends It's recommended to set as 3 when the encoder resolution
is 10,000.
If the resolution is 1,048,576, the value should be 314.
2021 Port No. of MPG 20
6.3 Setting About Spindle
Suppose the 4th axis is used as 1st spindle.
No. Name Value Description
24 Port No. of axis 1003 Suppose the station ID of Syntec 4-in-1 driver is 1.
64 Encoder resolution Depends Real encoder resolution divided by 4, unit：Pulse/Rev
84 Encoder scaling factor 4 Use default value
104 Gain of motor command Depends Real maximum speed of the motor divided by 10.
If the max. speed of the motor is 12,000 RPM, Pr104 should
be 1,200.
127~12
8
Gear number at the
screw side.
Gear number at the
motor side.
Depends
164 Pitch of the screw 360000 Unit：BLU
