              22/220 Series Controller Application Manual
Pitch Error Compensation–34
•
•
•
•
•
•
•
•
•
•
•
No Descriptions Range Unit Default Effective
3859 *High Precision Pitch Error
Compensation
[0~1] - 0 restart
0 : Disable high precision pitch error compensation
1~10 axis : the maximum compensated number is 100
11~18 axis : No compensation
1 : Enable high precision pitch error compensation
1~18 axis : the maximum compensated number is 2000
The relation between Pr1301~Pr1320 and Pr3859 as follow :
Axis ID Pr1301~Pr1320 Pr3859 = 0 Pr3859 = 1
1-10 axis 0 No compensation No compensation
1 Uni-directional
compensation
High Precision Uni-
directional compensation
2 Bi-directional
compensation
High Precision Bi-
directional compensation
11~18 axis 0 No compensation No compensation
1 No compensation High Precision Uni-
directional compensation
2 No compensation High Precision Bi-
directional compensation
Effective version：10.118.52G, 10.118.56A, 10.118.57 or abover.
No Descriptions Range Unit Default Effective
1301~1320 Pitch error compensation
type
[0~2] - 0 Press Reset
Set the param to decide to start compensation or not
0: No compensation;
1: Uni-directional;
2: Bi-directional.
In10.114.15 and before, only 6 axes are supported; after 10.114.16, supported number expanded to 10
axes.
In 10.118.52G, 10.118.56A, 10.118.56 or above version, supported number expanded to 18 axes in high
precision pitch error mode.
High-Precision pitch error configuration setting
