              22/220 Series Controller Application Manual
Pitch Error Compensation–35
•
•
•
•
•
•
•
•
•
•
•
•
•
Name Range Unit Default Effective
Start Point [-99999.999
~
99999.999]
mm/deg 0.000 Input
Set the mechanical position of the pitch compensation starting point.
The least significant digit is to the third decimal place, and the minimum unit is 0.001mm.
Name Range Unit Default Effective
Number [1~2000] - 2000 Input
Set the number of high-precision pitch compensation points.
If the machine travel exceeds the number of points, the excess part will maintain the previous
compensation value.
Name Range Unit Default Effective
Interval [-99999.999~99999.999] mm/deg 20.000 Input
Set the pitch error compensation interval.
The least significant digit is to the third decimal place, and the minimum unit is 0.001mm.
Name Range Unit Default Effective
Value [-999999.999~999999.999] um/mdeg 0.000 Input
Each pitch error compensation value.
Setting Example
Enable High-Precision Pitch Error Compensation ( Pr3859 = 1 )
Enable the first axis pitch error compensation in Bi-Direction mode( Pr1301 = 2)
Set High-Precision pitch error configuration
Start Point : -100.000
Interval : -10.000
Number : 6
