机床产品/Machine Tool Products
              –
              22/220 Series Controller Application Manual
Software InstallationData Backup/Restore–63
i.
ii.
iii.
OCUp.exe
OCDown.exe
welock.exe
User profile
DiskA (or DiskC, DiskC2)\OpenCNC\User\Registry.dat
Contents of the Windows Registry
HKLM\Init\*
HKLM\Software\Syntec\*
HKLM\System\CurrentControlSet\Control\Layouts\00000409\\PS2_AT
HKLM\Drivers\BuiltIn\TouchKit1
HKLM\Drivers\HID\LoadClients\Default\Default\1_6\Keyboard
HKLM\Comm\EMAC1\Parms\TCPIP
HKLM\Comm\ENET1\Parms\TCPIP
HKLM\Comm\DM9000\Parms\TCPIP
HKLM\Comm\PCI\E100CE1\Parms\TCPIP
HKLM\Comm\PCI\E1Q51CE61\Parms\TCPIP
HKLM\HARDWARE\DEVICEMAP\TOUCH
HKLM\Software\Microsoft\FontLink\SystemLink
Others
Windows folder
Boot Picture
File name: Bootcepc.bmp
Placed in BootPicture folder
Valid version: 10.116.34
Driver Parameters (the parameter backup file is only applicable for serial servo drives.
Contains Normal Axis, Serial PLC Axis, ROT Turret and ATC Axis)
Kernel Information (tooltable data: ToolTable.dat, M code scan records:
ScanTable.dat, Home info of Serial PLC Axis ROT Turret, ATC Axis)
Operation Log
System Information (including the controller and drivers, driver info is only valid for
serial servo drivers)
For version 10.116.36J, 10.116.42 and after, Machine Maker information is also
included.
Authority Information
File name: AuthoUser.xml
Record the authority definition.
Record Syntec customer service accounts.
Record Machinery Manufacturer's account & passwords.
Record all end-users account & passwords, and their authority content.
The file is encrypted, can not be edited.
Encoder Battery Information
Directory: BackupOnly\Syntec\BatteryLog*.dat (valid version: 10.118.12P,
10.118.21)
Syntec Standard Kernel Scope records (Alarm(1~3Axis), Service, Daily, Alarm(4~6Axis))
Directory: BackupOnly\Syntec\(Alarm / Service / Daily / Alarm456)
Valid version:
i.MX6 Controller:10.118.23W10.118.28J10.118.34
AM3354 Controller: 10.118.23X10.118.28K10.118.35
10.118.48P, 10.118.52J, 10.118.56D, 10.118.58 and later versions support
alarm record(4~6Axis).
MMILog
Directory: BackupOnly\Syntec
