              22/220 Series Controller Application Manual
Software Installation、Data Backup/Restore–64
•
•
•
•
•
•
•
•
•
•
•
i.
•
•
•
ii.
•
•
•
iii.
•
•
•
•
iv.
•
•
•
v.
•
•
vi.
•
•
vii.
•
•
•
viii.
•
•
•
•
•
•
•
Records the error message when system exception occurs, and diagnostic
information about MMI.
Valid version: 10.118.22Y, 10.118.23Y, 10.118.28L, 10.118.36
Renamed from Exception Logto MMILog after version: 10.118.30S, 10.118.32S,
10.118.40W, 10.118.42W, 10.118.48H, 10.118.52B, 10.118.53
Data Log
Valid version: 10.118.24E, 10.118.28R, 10.118.39
EncParameter
Folder name: EncParameter
Backed up files: All encoder parmeter tables of the CNC.
After the valid version: 10.118.56M, 10.118.60G, 10.118.66A, 10.118.67
If fail to back up EncParameter, recommand to execute EncParameter
exporting and find error code.
Maker Backup (MB) Files: (L = COM/CHT/CHS = languages)
Ladder Diagram
Folder name: Ladder
Ladder file name: cnc.lad
PLC alarm string file: AlarmPLC_L.xml
Parameter File
Folder name: Parameter
Parameter file name: param.dat
Parameter text file name: param.txt (plaintext file does not need special software to
open)
Extension Parameter File
Folder name: ParameterExt
Expansion parameter definition file: paramext.pxt
Expansion parameter stringfile: ParamExt_L.xml
Expansion parameter byte stringfile: ParamExt _RBit_L.xml
Macro Program
Folder name: MACRO
MACRO: * (user defined)
MACRO alarm string file: AlarmMacro_L.xml
Boot Picture
Folder name: BootPicture
User profile
Folder name: Registry
Filename: Registry.dat (including tool data/coordinates system/auto tool parameters/
work record/...etc)
Plug-in Module
Folder name: Plugin
Plug-in config file: Plugin.Config
Plug-in dynamic link libraries:. *.dll (user defined)
Customized HMI
Folder name: OCRes
Backed up files: All files except for the following four:
AlarmPLC_L.xml
AlarmMacro_L.xml
ParamExt_L.xml
ParamExt_RBit_L.xml
When backing up customized HMI under the connection structure between front/back
stage
