              22/220 Series Controller Application Manual
Software Installation、Data Backup/Restore–65
•
•
•
•
•
•
ix.
•
•
•
x.
•
•
•
•
•
•
•
xi.
•
•
•
•
•
•
xii.
•
•
•
xiii.
•
•
•
xiv.
1.
2.
xv.
•
•
xvi.
•
•
•
Versions after 10.116.24V, 10.116.36B, 10.116.37, 10.117.37 (not included)
Handheld pendant CE as front stage: The front stage of customized HMI
will be backed up for displaying the customized screen; if the backup of
back stage is needed, please run the backup through the machine end of
back stage.
PC as front stage: Not supporting
Versions after 10.118.9, 10.118.0I (not included)
Handheld pendant CE as front stage: The front stage of customized HMI
will be backed up for displaying the customized screen; if the backup of
back stage is needed, please run the backup through the machine end of
back stage.
PC as front stage：The front stage of customized HMI will be backed up
History Alarm
Folder name: HistoryAlarm
Existing Alarm: Actalm.txt
History Alarm: Histalm.txt
Drive Parameters
Folder name: DriveParameter
Drive parameter filename: TunningParam.dat
Drive parameter text filename: TunningParam.txt
Serial PLC axis drive parameter file: M2/M3_SPLCA_SerialParam.dat
ROT drive parameter file:M2_ROT_SerialParam.dat
ATC drive parameter file: M2/M3_ATC_SerialParam.dat
Requires serial communication controller and the drive to complete the backup
successfully
Authority Data
Folder name: AuthoData
File name: Autho.xml.
Record end-user administrator's password
Record all end-users' account & passwords, and their authority content.
Record Machinery Manufacturer's account & passwords.
The file is encrypted, can not be edited.
Serial PLC Axis (SPLCA) Parameters
Folder name: SPLCAData
File name: SerialParam.dat
Requires a serial system and succeeded drive communication to complete the backup.
ROT Turret Data
Folder name: ROTData
File name: ROTParam.dat
Requires a serial system and succeeded drive communication to complete the backup.
Data Log
Folder name: DataLog
File name: DataLogx.dat (x is a number from 0 to 2, the greater the number represents
the longer duration)
Operation Log
Folder name: OPLog
File name: OPLog.x (x is a number from 0 to 2, the greater the number represents the
longer duration)
Kernel Data
Folder name: SysData
Tool table data file: ToolTable.dat(Valid version: after10.116.36D, 10.116.39)
M code group file: ScanTable.dat(Valid version: after10.116.24X, 10.116.36D,
10.116.39)
