              22/220 Series Controller Application Manual
Software Installation、Data Backup/Restore–66
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
xvii.
•
•
•
xviii.
•
•
xix.
•
•
xx.
•
•
•
•
xxi.
•
•
•
•
•
xxii.
1.
•
•
•
•
•
2.
Record Home info of Serial PLC Axis and ROT Turret
Folder name: SysData
Machinery manufacturer's data folder: DiskC\MakerData
M3 device object registry file (M3-IO only), M3HwInfo.dat
Laser marking parameter data LaserCtrlParam.dat,
LaserGeomAxisParamX.dat(X is a number from 1~3)
Auto tool changing (ATC) parameter data: ATCParam.dat
End-user data folder: DiskC\MachineData
Laser marking galvo motor distortion correction table: DCTData.dat
ROT customized tool position table: RotPosParam.dat
Auto tool changing (ATC) origin data: ATCReg.dat
High-Precision Pitch Table : HighPrecisionPitchComp.dat
Commonly used end-user data folder: DiskA\MachineData
ROT customized tool position table: RotPosParam.dat
Laser marking registry file: LaserReg.Dat
Tool table: ToolTable.dat
EnIP device data flie: EnIP_Config.xml
Machinery Manufacturer Information
Folder name: MakerInfo
File name: MakerConfigInfo.xml (Valid version: after 10.116.36J, 10.116.42)
Record the Machine Maker screen information
I/O Chart Information
Folder name: IOMap
File name: IoMap_Customer.xml (Valid version: after 10.116.38F, 10.116.54D,
10.118.0B, 10.118.2)
SRI Data
Folder name: SriParameter
File name: SriParam.dat、SriReg.dat
App Data
Folder name: App
Backed up files: DiskC\AppAll files ( Valid version: after 10.118.40B, 10.118.41 )
After the valid version: 10.116.56I, 10.116.60C, 10.118.62, the backup paths
of DiskC\App are different, so the backup can not be restored across the
compatibility version.
Backed up files: DiskA\App All files ( Valid version: after 10.116.56I, 10.116.60C,
10.118.62 )
EncParameter
Folder name: EncParameter
Backed up files: All encoder parmeter tables of the CNC.
After the valid version: 10.118.56M, 10.118.60G, 10.118.66A, 10.118.67
If fail to back up EncParameter, recommand to execute EncParameter exporting and
find error code.
Not Support for front/back stage
Other Information
System Information
Folder name: SystemInfo Txt
Controller Information: SystemInformation.txt
Machine Manufacturer Info added for versions10.116.36J, 10.116.42 and
later.
Drive Information: SerialServoInformation.txt
Requires a serial system and succeeded drive communication to
complete the backup.
Encoder Battery Information
