              22/220 Series Controller Application Manual
Software Installation、Data Backup/Restore–68
•
•
•
7.
a.
b.
c.
8.
a.
b.
c.
9.
a.
b.
c.
10.
a.
b.
c.
11.
a.
b.
c.
•
•
•
•
•
•
•
•
•
•
•
Directory：BackupOnly\Syntec
FileName：CollisionLog*.dat
Valid version：10.118.40D, 10.118.42
RDLog
Directory：BackupOnly\Syntec\RDLog
FileName：RDLog*.dat
Valid version：10.118.40Y, 10.118.42Y, 10.118.48J, 10.118.52D, 10.118.54
ScopeLog
Directory：BackupOnly\Syntec\ScopeLog
FileName：ScopeLog*.dat
Valid version：10.118.40Y, 10.118.42Y, 10.118.48J, 10.118.52D, 10.118.54
SystemBootLog
Directory：BackupOnly\Syntec\SystemBootLog
FileName：SystemBootLog*.dat
Valid version：10.118.44B, 10.118.46B, 10.118.48M, 10.118.52G, 10.118.56A,
10.118.57
OperationLog
Directory：BackupOnly\Syntec\RDLog
FileName：OperationLog*.dat
Valid version：10.118.48W, 10.118.52Q, 10.118.56K, 10.118.60E, 10.118.66
IO Log
Directory：BackupOnly\Syntec\IOLog
FileName：IOLog*.dat
Valid version：10.118.44C, 10.118.46C, 10.118.48N, 10.118.52H, 10.118.56B,
10.118.57
Operation Steps
Enter "Backup Sys." and select the files to back up, or select "Syntec Backup", or press "Internal
Backup".
Press "Next" after selection, the backup path window will appear. If chose the "Internal Backup", the
back up system will start automatically without other operations.
The path selecting window on PC is the same as the one on controller, provides USBDisk,
DiskA and Network folder. For USBDisk and DiskA, the folder content of root directory where
the project is saved will be obtained.
For example: Save the project with PC as front stage in folder C:\Project\21MA , the path of
DiskA on the path selecting window will be C:\DiskA.
Valid versions for front/back stage MB function with PC as front stage: 10.118.10,
10.118.0J(included) and later.
Select the destination path and press "Enter".
Edit file name for the backup file, default name will be given if no change is required. After the editing
is complete, press "Next".
Note: No special symbols can be used in the file name, including < > / \ | : " * ? etc.
Edit file comment (could be blank). After the editing is complete,press "Next".
A message will appear to ask whether to start the backup, press "Ok" to start. To return to previous
step, press "ESC" to go backward.
After the backup is complete, another hint message will appear.
Data backup screen
