              22/220 Series Controller Application Manual
Hardware List & Descriptions–9
G Encoder port Connect to motor encoders, the order is1st/2nd/
3rd/4th form top to bottom.
H MPG port（optional） Connect to hand-wheel.
I X1 input port（optional） Same as X1 on the controller, connect to input
terminal board.
J Y1 output port（optional） Same as Y1 on the controller, connect to output
terminal board.
MiniUSB Encoder
