102 Reciter Disassembly and Reassembly TB8100 Service Manual
© Tait Electronics Limited September 2006
4.4 Refitting the Front and Rear Panels
The circled numbers in the following instructions refer to Figure 4.1.
1. If removed previously, refit the fan duct
f to the heatsink and secure
with the two M3 Torx screws.
2. Refit the front panel and secure to the heatsink with the M3 Torx
screw
e.
3. Secure the handle to the heatsink with the two M3 Torx screws
d.
4. Secure the SMA connector to the heatsink and front panel with the
four M2.5 Torx screws
b.
5. Resolder the centre pin of the SMA connector
c to the RF board.
6. Refit the rear panel to the heatsink and secure with the two M3 Torx
screws
h. If you have removed the rear panel on the RF side,
reconnect the coaxial cables to the RF board.
7. Refit the vent guard clip
g.
4.5 Refitting the Covers
1. Slide each cover into place over the front and rear panels. Make sure
the holes in the covers line up with the threaded holes in the heatsink
and front and rear panels.
2. Press the covers firmly into place and secure with the M3 Torx screws.
Note The covers are not interchangeable. Each cover must be fitted to
the correct side and in the correct orientation.
