18 Safety and Servicing Information TB8100 Service Manual

1.3 Regulatory Information

1.3.1 Distress Frequencies

The 406 to 406.1MHz frequency range is reserved worldwide for use by

Distress Beacons. Do not program transmitters to operate in this frequency

range.

1.3.2 FCC Compliance

This device complies with part 15 of the FCC Rules. Operation is subject

to the condition that this device does not cause harmful interference.

1.3.3 Unauthorised Modifications

Any modifications you make to this equipment which are not authorised by

Tait Electronics Limited may invalidate your compliance authority’s approval

to operate the equipment.

1. Refer to the TB8100 Specifications Manual (MBA-00001-xx) for more information on the

compliance standards to which TB8100 equipment has been tested and approved.
